FEATURES
• Distance up to 120m – 4K @30Hz
• IR Passback Function
• HDbitT Technology
SPECIFICATIONS
• HDMI Signal: HDMI 1.4, Compliant with HDCP
• Network Bandwidth: 18Mbps
• Supported Resolutions: 480i @60Hz, 480p @60Hz, 576i @50Hz, 576p @50Hz, 720p @50/60Hz, 1080i @50/60Hz, 1080p @50/60Hz, 4K @24/25/30Hz
• Audio Format Supported: PCM
• TMDS Signal: 0.7~1.2 Vp‑p
• DDC Signal: 5Vp‑p (TTL)
• Remote Control: Supported
• IR Passback: Supports 20~60KHz IR Devices
• Matrix Configuration: up to 100× Source Signals Can Be Connected and Switched to Infinite Output
• Power Supply: DC 5V 2A
• Power Consumption: TX 6W, RX 5W
• Weight: TX 320g, RX 310g
• Dimensions (L × W × H): 164 × 107.6 × 23.6mm
• Working Temperature: 0~60°C
• Storage Temperature: –20~70°C
• Humidity (No Condensation): 0~95%
• Colour: Black
• Protection: Lightning, Surge and ESD Protection
