FEATURES
• Lower Latency Transmission up to 120m
• One-to-One or One-to-Many
• IR Passback
• Lightning, Surge and ESD Protection
SPECIFICATIONS
• HDMI Signal: Compatible With HDCP
• Supported Resolutions: 480i @60Hz, 480p @60Hz, 576i @50Hz, 576p @50Hz, 720p @50/60Hz, 1080i @50/60Hz, 1080p @50/60Hz, 4K @24/25/30Hz
• Network Cable: UTP/STP CAT6
• Transmission Distance: up to 120m for 1080p @60Hz Full HD over Single CAT6
• IR Signal Support: Supports 20~60KHz IR Devices
• Working Temperature: 0~60°C
• Power Supply: DC 5V 2A (Adapter Not Included)
• Power Consumption: TX 4.5W, RX 3.5W
• Protection: Lightning, Surge and ESD Protection
• Dimensions (W × D × H): TX/RX 107.3 × 94 × 23.7mm each
• PoE Input: Supports IEEE802.3af with 10W Input Power
• Weight: TX/RX 275g Each
• Colour: Black
