FEATURES
• 300Mbps wireless speed is ideal for HD streaming, online gaming, and large file downloads
• Three 5dBi antennas greatly increase wireless signal strength, size and stability
• Intuitive webpage guides you through the setup process in minutes
SPECIFICATIONS
• Dimensions: (W X D X H)169 x 116 x 35 mm
• External Power Supply: 5VDC/0.6A
• Antenna Type: 3 x 5dBi fixed omni directional antennas
• Signal Rate:
– 11n: Up to 300Mbps (Dynamic)
– 11g: Up to 54Mbps (Dynamic)
– 11b: Up to 11Mbps (Dynamic)
• Button: Reset/WPS button
• Wireless Standards: IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
• Frequency: 2.4 – 2.4835GHz
• Reception Sensitivity:
– 270M: -70dBm@10% PER
– 130M: -74dBm@10% PER
– 108M: -74dBm@10% PER
– 54M: -77dBm@10% PER
– 11M: -87dBm@8% PER
– 6M: -90dBm@10% PER
– 1M: -98dBm@8% PER
• Interfaces: 3 10/100Mbps LAN ports, 1 10/100Mbps WAN port
• Certifications: CE, ROHS
• Transmission Power: <20dBm
• Wireless Security: 64128152-bit WEP >
