FEATURES
• High-Speed Wi-Fi – Stream with fast and stable connections, reaching speeds up to 1167Mbps (300Mbps on the 2.4GHz band and 867Mbps on the 5GHz band)
• 4 High-Gain External Antennas – Receive strong Wi-Fi signals in every corner of your home
• Easy Installation – Setup in minutes guided by an intuitive web UI
• Active Parental Controls – Protect your family by setting appropriate access policies for responsible, safe internet use
• Multi-Mode – Access Point Mode, Range Extender Mode and Router Mode supported to satisfy all application scenarios
• IPTV and IPv6 Supported
SPECIFICATIONS
• Ethernet Ports: 1x 10/100 Mbps
• WAN Port: 2x 10/100 Mbps LAN Ports
• Button: Reset/WPS Button
• External Power Supply: 9V/0.85A
• Dimensions: (W x D x H) 114 x 94 x 26 mm
• Antenna: 4x 5 dBi Fixed Omni-Directional Antennas
• Wireless Standards: IEEE 802.11ac/n/a 5 GHz, IEEE 802.11b/g/n 2.4 GHz
• Frequency: 2.4 GHz, 5 GHz
• Signal Rate: Up to 300 Mbps on 2.4 GHz, 867 Mbps on 5 GHz
• EIRP: 2.4 GHz < 20dBm (EIRP)5 GHz < 23dBm (EIRP)
• Reception Sensitivity: 11g 6Mbps: -96dBm11g 54Mbps: -78dBm11n HT40 MCS7: -74dBm11n HT20 MCS7: -71dBm11a 6Mbps: -97dBm11a 54Mbps: -79dBm11ac VHT20 MCS8: -74dBm11ac VHT40 MCS9: -70dBm11ac VHT80 MCS9: -65dBm
• Wireless Function: Enable/Disable Wireless Radio, WMM
• Security Features: Simple Parental Controls, Guest Network Access
• Wireless Security: WEP, WPA / WPA2-Personal, WPA2 / WPA3-Personal
