FEATURES
• AX3000 Dual-Band Wi-Fi Speeds – Up to 3,000Mbps with 2,402Mbps on 5.0GHz and 574Mbps on 2.4GHz
• High-Efficiency Wi-Fi 6 Technology – Supports OFDMA and improved efficiency for better performance with multiple devices
• Gigabit Wired Connection – Provides high-speed wired connectivity for PCs, IPTV and gaming consoles
• Smart Signal Indicator – Helps you find the optimal placement for the best Wi-Fi coverage
• Easy One-Touch Setup – Press the WPS button to expand your Wi-Fi coverage in seconds
• Flexible Operation Modes – Supports both Range Extender Mode and Access Point Mode
• App-Based Network Management – Set up and manage your Wi-Fi easily through the Mercusys App on iOS or Android devices
SPECIFICATIONS
WIRELESS STANDARDS
• IEEE 802.11a/n/ac/ax (5.0GHz)
• IEEE 802.11b/g/n/ax (2.4GHz)
FREQUENCY
• 2.4GHz
• 5.0GHz
SIGNAL RATE
• 574Mbps (2.4GHz)
• 2,402Mbps (5.0GHz)
RECEPTION SENSITIVITY
5.0GHz
• 11a 6Mbps: -97dBm
• 11a 54Mbps: -78dBm
• 11ax HE20 MCS0: -96dBm
• 11ax HE20 MCS11: -66dBm
• 11ax HE40 MCS0: -93dBm
• 11ax HE40 MCS11: -62dBm
• 11ax HE80 MCS0: -90dBm
• 11ax HE80 MCS11: -60dBm
• 11ax HE160 MCS11: -58dBm
2.4GHz
• 11g 6Mbps: -96dBm
• 11g 54Mbps: -78dBm
• 11ax HE20 MCS0: -96dBm
• 11ax HE20 MCS11: -66dBm
• 11ax HE40 MCS0: -93dBm
• 11ax HE40 MCS11: -62dBm
WIRELESS SECURITY
• WEP
• WPA
• WPA2
• WPA3-PSK
DIMENSIONS (W × D × H)
• 138.6 × 100.3 × 68.4mm
INTERFACES
• 1× Gigabit Ethernet Port
BUTTON
• WPS / Reset Button
ANTENNA TYPE
• 2× External Antennas
POWER CONSUMPTION
• 13W
CERTIFICATIONS
• RoHS
ENVIRONMENT
• Operating Temperature: 0~40°C
• Operating Humidity: 10~90% Non-Condensing
