Sinotec 1/4” SHARP CCD Dome Camera, Retail Box, 1 Year warranty.
Product Overview
The Sinotec SD501-P4 dome camera features a 1/4” SHARP CCD image sensor delivering a resolution of 420 TVL for clear, detailed video. It supports both PAL and NTSC TV systems and offers 30 meters of IR night vision with 36 IR LEDs for effective low-light surveillance. Equipped with a built-in 3.6 mm F2.0 lens and powered by DC 12V, this compact dome camera is ideal for various indoor security applications.
Specifications:
• Product Code: SD501-P4
• Description: Sinotec 1/4” SHARP CCD Dome Camera
• Image Sensor: 1/4″ SHARP CCD
• Resolution: 420TVL
• Pixels: PAL:500(H)x582(V) NTSC:510(H)x492(V)
• TV System: PAL/NTSC
• Sync System: Internal Synchronization
• Usable Illumination: 0.1Lux
• S/N Ratio: ≥48 dB (AGC OFF)
• Video Out: Composite Signal (1.0Vp-p,75Ω)
• Scanning System: PAL:625 Lines, 50 field/sec; NTSC:525 Lines, 60 filed/sec
• Electronic Shutter Time: PAL 1/50-1/100,000SEC; NTSC 1/60-1/100,000SEC
• White Balance & AGC: Auto
• IR Distance: 30M
• IR LED: 36 pcs ￠5mm
• Built-in 3.6 mm Board Lens/F2.0
• Power Supply: DC 12V
• Product Dimension (mm): 77(H)*94(D)
• Box Dimension (mm): 90*100*100
• Weight (Gross) (Kg): 0.19
• Weight (Net) (Kg): 0.23
