Solarix Solar Charge Controller MPPT 12V / 24V 30A – Solar controller charger for Home use, 30A 12V / 24V, LCD Display, Solar Panel Power: 390W (12V), 780W (24V), Intelligent MPPT Charge Mode, Retail Box, 1 Year Warranty
Product Overview
This Solarix Solar Charge Controller archives Maximum power of the solar panel: 30A (Automatically switches between 12V and 24V) this controller-regulator is designed for charging batteries through a solar panel. When the battery voltage is not sufficient, the controller plays a protective role, preventing the voltage from falling below that required to charge the battery.
Product Features
•Humanization LCD Display
•MPPT 4 Stage charging
•Load working mode optional
•Light sensor and timer programmable
•Battery type flood, lead-acid, GEL, Lithium optional
•Charge and discharge current display
•Overall Effective protection
Specifications
•Stock Code: SOLMPPT122430
•Description: Solarix Solar Charge Controller MPPT 12V / 24V 30A
•Type: MPPT
•System Voltage: 12V/24Auto
•Solar Panel Maximum Voltage Voc: 100V
•Maximum Open Voltage: 55V – 100V
•Maximum Output Current: 30A
•Solar Panel Power: 390W (12V), 780W (24V)
•Battery voltage: 12V-24V
•Battery Voltage Range: 8-32V
•Battery type: lead acid (sealed, gel) and lithium (also can be customized for different types of batteries)
•Waterproof level: IP30
•Standby power consumption: 8mA (12V), 12mA (24V)
•Overload protection: <10S
