FEATURES
• Supports AHD/TVI/CVI/CVBS/IP video inputs
• Supports VGA, HD-OUT, CVBS output
• Easy to use Same Interface of GUI/WEB/Client
• Support various mobile monitoring:（IOS, Android)
• Support more than languages
• Perfect protection circuit, unique triple watchdog function
• Supporting web, IMS, provide SDK development
SPECIFICATIONS
System
• Main Processor: Embedded processor
• Operating System: Embedded LINUX
Video and Audio
• Analog UE Camera Input: 4ch BNC
• AHD Camera: 1080p / 720P / 960H @25/30fps
• TVI Camera: 1080p / 720P / 960H @25/30fps
• CVI Camera: 1080p / 720P / 960H @25/30fps
• CVBS Camera: PAL/NTSC
• IP Camera Input: 4ch, each channel up to 1080p
• Audio In/Out: 4ch input, 1ch output, RCA
Two-way Talk: N/A
Display
• Interface: 1ch HD-OUT, 1ch VGA, 1ch CVBS
• Resolution: HD-OUT: 1920×1080, 1280×1024, 1440×900
• VGA: 1920×1080, 1280×1024, 1440×900
• Multi-screen Display: 1/4
Recording
• Compression: H.264 High Profile
• Resolution: 1080p/720P/960H
• Record Rate: 1080p @12fps, 960H (1~25/30fps)
• Bit Rate: 1~6144Kbps Per Channel
• Record Mode: Manual, Event, Timer
• Record Interval: Post-record: 5~60 sec
Video Detection and Alarm
• Trigger Events: Recording, Buzzer, Push message, Pop up message
• Video Detection: Motion Detection, Video Loss, Camera Tamper
• Alarm input: N/A
Network
• Interface: 1 RJ-45 port (10/100Mbps)
• Network Function: HTTP, TCP/IP, UDP, NTP, DHCP, DNS, IP Filter, DDNS,
• Max. User  Access: Access 3 users
• Smart Phone: iPhone, iPad, Android
• Interoperability: ONVIF 2.6, SDK
Playback and Backup
• Playback: 4/1
• Search Mode: Time /Date, Alarm, Picture Grid, Event
• Playback Function: Play, Pause, Stop, Next Frame, Fast play, Slow Play, Layout, Shuffle, Backup Selection,
Digital Zoom
• Backup Mode: USB HDD
Storage
• Internal HDD: 1 SATA Ports, up to 6TB for each HDD
• Mounting Mode: Embedded
eSATA: N/A
Interface
• USB Ports: 2× USB2.0
• RS232:  N/A
• RS485: 1 Port, for PTZ Control
General
• Power Supply: DC12V 2A
• Power Consumption: Max 5W (without  HDD)
• Operating Temperature: -10 °C ~ 50°C
• Strorage Conditions: Less than 90% RH
• Certifications: CE/FCC
• Dimensions (L × W × H): 255 × 244 × 44mm
• Net Weight: 900g
