FEATURES
• Supports AHD/TVI/CVI/CVBS/IP video inputs
• Supports VGA, HD-OUT, CVBS output
• Easy to use Same Interface of GUI/WEB/Client
• Support various mobile monitoring:（IOS, Android)
• Support more than languages
• Perfect protection circuit, unique triple watchdog function
• Supporting web, IMS, provide SDK development
SPECIFICATIONS
System
• Main Processor: Embedded processor
• Operating System: Embedded LINUX
Video and Audio
• Analogue Camera Input: 8ch BNC
• AHD Camera: 1080p / 720p / 960H @25/30fps
• TVI Camera: 1080p / 720p / 960H @25/30fps
• CVI Camera: 1080p / 720p / 960H @25/30fps
• CVBS Camera: PAL/NTSC
• IP Camera Input: 8ch, each channel up to 1080p
• Audio In/Out: 8ch input, 1ch output, RCA
Two-way Talk: N/A
Display
• Interface: 1ch HD-OUT, 1ch VGA, 1ch CVBS
• Resolution: HD-OUT: 1920×1080, 1280×1024, 1440×900
• Resolution: VGA: 1920×1080, 1280×1024, 1440×900
• Multi-screen Display: 1/4/9
Recording
• Compression: H.264 High Profile
• Resolution: 1080p/720p/960H
• Record Rate: 1080p @12fps、960H (1~25/30fps)
• Bit Rate: 1Kbps ~ 6144Kbps Per Channel
• Record Mode: Manual, Event, Timer
• Record Interval: Post-record: 5 ~ 60s
Video Detection and Alarm
• Trigger Events: Recording, Buzzer, Push Message, Popup Message
• Video Detection: Motion Detection, Video Loss, Camera Tamper
• Alarm in/out: 4/1
Network
• Interface: 1 RJ-45 port (10/100Mbps)
• Network Function: HTTP, TCP/IP, UDP, NTP, DHCP, DNS, IP Filter, DDNS,
• Max. User Access: Access 5 users
• Smart Phone: iPhone, iPad, Android
• Interoperability: ONVIF 2.6, SDK
Playback and Backup
• Playback: 8/4/1
• Search Mode: Time /Date, Alarm, Picture Grid, Event
• Playback Function: Play, Pause, Stop, Next Frame, Fast play, Slow Play, Layout, Shuffle, Backup Selection, Digital Zoom
• Backup Mode: USB HDD
Storage
• Internal HDD: 2 SATA Ports, up to 6TB for each HDD
• Mounting Mode: Embedded
• eSATA: N/A
Interface
• USB Ports: 2× USB2.0
• RS232: N/A
• RS485: 1 Port, for PTZ Control
General
• Power Supply: DC12V 4A
• Power Consumption: Max. 10W (without HDD)
• Operating Temperature: -10°C ~ 50°C
• Strorage Conditions: Less than 90% RH
• Certifications: CE/FCC
• Dimensions (L × W × H): 350 x 305 x 49mm
• Net Weight: 1900g
