FEATURES
• Built For Outdoor Wi-Fi – Designed for reliable performance in demanding outdoor environments
• 300Mbps 2×2 MIMO Performance – Delivers stable high-speed wireless connectivity
• High-Power Long-Range Coverage – High transmission power and high-gain antennas extend coverage distance
• Weatherproof Industrial Design – Durable enclosure engineered to withstand harsh weather conditions
• Flexible Passive PoE Deployment – Simplifies installation with power and data over a single cable and easy mounting options
• Cloud-Based Omada Management – Free centralised management via cloud platform and Omada App for streamlined control
• Advanced Guest Network And Security – Multiple authentication options including SMS, Facebook and Voucher with robust wireless protection
• Management VLAN Support – Enables enhanced network segmentation and administration
SPECIFICATIONS
HARDWARE FEATURES
• Interface: 1× Fast Ethernet (RJ45) Port (Supports Passive PoE)
• Button: Reset
POWER SUPPLY
• 24V Passive PoE (+4,5pins; -7,8pins)
• PoE Adapter Included
POWER CONSUMPTION
• 3.12W
DIMENSIONS (W × D × H)
• 216 × 46 × 27mm
ANTENNA
• 2× 3dBi External Omni Waterproof Antennas
WEATHERPROOF ENCLOSURE
• IP65
MOUNTING
• Pole and Wall Mounting Kits Included
WIRELESS FEATURES
WIRELESS STANDARDS
• IEEE 802.11n/g/b
FREQUENCY
• 2.4GHz
SIGNAL RATE
• 802.11n: up to 300Mbps (Dynamic)
• 802.11g: up to 54Mbps (Dynamic)
• 802.11b: up to 11Mbps (Dynamic)
TRANSMIT POWER
• CE: ≤20dBm (EIRP)
• FCC: ≤22dBm
WIRELESS FUNCTIONS
• Multiple SSIDs (up to 8× SSIDs)
• Enable/Disable Wireless Radio
• Automatic Channel Assignment
• Transmit Power Control
• QoS (WMM)
• Load Balance
• Rate Limit
• Reboot Schedule
• Wireless Schedule
• Wireless Statistics (SSID/AP/Client Based)
WIRELESS SECURITY
• Captive Portal Authentication
• Access Control
• Wireless MAC Address Filtering
• Wireless Isolation Between Clients
• SSID to VLAN Mapping
• Rogue AP Detection
• 802.1X Support
• 64/128/152-bit WEP
• WPA/WPA2-Enterprise
• WPA-PSK/WPA2-PSK
MANAGEMENT
• Omada Cloud Access
• Omada App
• Omada Cloud Controller
• Omada Controller Software
• Auranet Controller Software
• Email Alerts
• LED On/Off Control
• Management MAC Access Control
• SNMP
• System Logging (Local/Remote Syslog)
• Telnet
• SSH
• Web-Based Management (HTTP/HTTPS)
• L3 Management
• Multi-Site Management
• Management VLAN
CERTIFICATION
• CE
• FCC
• RoHS
SYSTEM REQUIREMENTS
• Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows 10
