FEATURES
• Boosts your existing Wi-Fi coverage to deliver fast and reliable wired and wireless connectivity
• External antennas for faster and more reliable Wi-Fi
• Supports AP mode which creates a new Wi-Fi Access point
• Easily expand wireless coverage at a push of the Range Extender button
• Set the Power Schedule for the range extender for power-saving
• Works with Any Wi-Fi Router
SPECIFICATIONS
HARDWARE FEATURES
• Interface: 1: 10/100M Ethernet Port (RJ45)
• Button: WPS Button, Reset Button
• Power Consumption: 3.6W
• Dimensions (W x D x H): 80 x 77.8 x 77.3mm
• Antenna: 2x external
WIRELESS FEATURES
• Wireless Standards: IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
• Frequency: 2.4~2.4835GHz
• Signal Rate:
– 11n: Up to 300Mbps (dynamic)
– 11g: Up to 54Mbps (dynamic)
– 11b: Up to 11Mbps (dynamic)
• Reception Sensitivity:
– 270M: <-68dBm@10% PER
- 130M: <-68dBm@10% PER
- 108M: <-68dBm@10% PER
- 54M: <-68dBm@10% PER
- 11M: <-68dBm@8% PER
- 6M: <-68dBm@10% PER
- 1M: <-68dBm@8% PER
• Transmit Power: < 20 dBm (EIRP)
• Wireless Modes: Range Extender/Access Point
• Wireless Functions: Wireless MAC Address Filtering
• Domain Login Function
• Transmit Power Control
• Wireless Security: 64/128/152-bit WEP
• WPA-PSK / WPA2-PSK
OTHERS
• Certification: CE, RoHS
• System Requirements: Microsoft Windows 98SE, NT, 2000, XP, Vista or Windows 7, 8, 8.1, 10, Mac OS, NetWare, UNIX or Linux
