FEATURES
• Range Extender mode boosts wireless signal to previously unreachable or hard-to-wire areas flawlessly
• Miniature size and wall-mounted design make it easy to deploy and move flexibly
• Easily expand wireless coverage at a push of Range Extender button
• Ethernet port allows the Extender to function as a wireless adapter to connect wired devices
• Tether App allows easy access and management using any mobile device
• LED Control function includes a Night Mode for peaceful sleep
HARDWARE FEATURES
• Interface: 1 x 10/100M Ethernet Port (RJ45)
• Button: RE (Range Extender) Button, Reset Button
• Power Consumption: About 3W
• Wireless Standards: IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
• Dimensions (W x D x H): 110.0 x 65.8 x 75.2mm
• Antenna: 2 x internal
WIRELESS FEATURES
• Frequency: 2.4~2.4835GHz
• Signal Rate:
– 11n: Up to 300Mbps (dynamic)
– 11g: Up to 54Mbps (dynamic)
– 11b: Up to 11Mbps (dynamic)
• Reception Sensitivity:
– 270M: -68dBm@10% PER
– 130M: -68dBm@10% PER
– 108M: -68dBm@10% PER
– 54M: -68dBm@10% PER
– 11M: -85dBm@8% PER
– 6M: -88dBm@10% PER
– 1M: -90dBm@8% PER
• Transmit Power: < 20 dBm (EIRP)
• Wireless Modes: Range Extender/Access Point
• Wireless Functions: WMM (Wi-Fi Multimedia)
• Wireless MAC Address Filtering
• Wireless Statistic
• Domain Login Function
• Wireless Security: 64/128/152-bit WEP
• WPA-PSK / WPA2-PSK
OTHERS
• Certification: CE, RoHS
• System Requirements: Microsoft Windows 98SE, NT, 2000, XP, Vista or Windows 7, 8, 10, Mac OS, NetWare, UNIX or Linux
