FEATURES
• Unrivalled Wi-Fi 6 Speed – Breaks the Gigabit barrier with speeds up to 1,201Mbps (5.0GHz) and 574Mbps (2.4GHz)
• Wider Signal Coverage – Connect to your Wi-Fi in more parts of your home with two external high-gain antennas ensuring greater coverage and enhanced stability
• Bluetooth 5.2 – The latest Bluetooth technology achieves 2× Faster Speed and 4× Broader Coverage than BT4.2
• Improved Security – The latest security enhancements WPA3 provides enhanced protection in personal password safety
• Backward Compatibility – Full support for 802.11ax/ac/a/b/g/n standards
SPECIFICATIONS
WIRELESS PERFORMANCE
• AX1800 Wi-Fi 6: up to 1,201Mbps on 5.0GHz and 574Mbps on 2.4GHz
• Wireless Standards: IEEE 802.11a/b/g/n/ac/ax
• Bluetooth 5.2: Faster Speeds and Improved Stability
• Wireless Modes: Infrastructure Mode
• Wireless Security: 64/128-bit WEP, WPA/WPA2/WPA3, WPA-PSK/WPA2-PSK, 802.1X
• Modulation: up to 1024-QAM
HARDWARE
• Interface: PCIe
• Antennas: 2× High-Gain Dual-Band Antennas
• Dimensions: 120.8 × 78.5 × 20.9mm
• Chipset: Realtek Wi-Fi 6
TRANSMISSION POWER
• 5.0GHz: up to 23dBm (EIRP)
• 2.4GHz: up to 20dBm (EIRP)
COMPATIBILITY
• Windows 11/10 (64-bit Only)
