FEATURES
• Ultra-Fast Broadband Connection – Supports Sub-6GHz 5G technology which boosts download speeds up to 3.4Gbps
• Ultra-Low Latency – 5G brings responsive network connections with only 1ms latency
• AX3000 Dual-Band Wi-Fi 6 Speed – 2402Mbps (5.0GHz) plus 574Mbps (2.4GHz)
• 2.5 Gigabit Wired Connections – 1× 2.5Gbps port plus 2× Gigabit ports
• Mesh Network – Deco mesh technology ensures strong Wi-Fi signals everywhere
• Flexible Network Access – 4G, 5G and Fixed-Line Internet Access
• Simplified Setup – Easily set up and manage your network with the TP-Link Deco App
• TP-Link HomeShield – Provides comprehensive network protection, robust parental controls and real-time loT security
SPECIFICATIONS
WIRELESS STANDARDS
• Wi-Fi 6
• IEEE 802.11ax/ac/n/a 5GHz
• IEEE 802.11ax/n/b/g 2.4GHz
WI-FI SPEEDS
• AX3000
• 5GHz: 2,402Mbps (802.11ax)
• 2.4GHz: 574Mbps (802.11ax)
WI-FI RANGE
• 1–3 Bedroom Houses
• TP-Link Mesh Technology
• Optional Ethernet Backhaul
• 4× LTE/5G Internal Antennas plus 2× Wi-Fi Internal Antennas
• 2× External RP-SMA-F Antenna Interface
• Signal-Boosting Antenna Array
WI-FI CAPACITY
• Dual-Band
• MU-MIMO
• OFDMA
• 4× Streams
WORKING MODES
• 5G/4G Router
• Router
• Access Point
SECURITY
NETWORK SECURITY
• SPI Firewall
• Access Control
• HomeShield Security
• Real-Time IoT Protection
• Malicious Site Blocker
• Intrusion Prevention System
• DDoS Attack Prevention
• Home Network Scanner
GUEST NETWORK
• 1× 5.0GHz Guest Network
• 1× 2.4GHz Guest Network
WI-FI ENCRYPTION
• WPA-Personal
• WPA2-Personal
• WPA3-Personal
HARDWARE
PORTS AND CONNECTIONS
• 1× 2.5Gb Port plus 2× 1Gb Ports (WAN/LAN Auto-Sensing)
5G COMPATIBILITY
• 5G: N1/N3/N5/N7/N8/N20/N28/N38/N40/N41/N77/N78
4G COMPATIBILITY
• 4G FDD-LTE: B1/B3/B5/B7/B8/B20/B28
• 4G TDD-LTE: B38/B40/B41/B42/B43
3G COMPATIBILITY
• B1/B5/B8
SOFTWARE
PROTOCOLS
• IPv4
• IPv6
SERVICE KIT
• HomeShield
WAN TYPES
• Dynamic IP
• Static IP
• PPPoE
• L2TP
• PPTP
QUALITY OF SERVICE
• HomeShield QoS
• QoS by Device
CLOUD SERVICE
• OTA Firmware Upgrade
• TP-Link ID
• DDNS
NAT FORWARDING
• Port Forwarding
• UPnP
IPTV
• IGMP Proxy
• IGMP Snooping
• Bridge
• Tag VLAN
DHCP
• Address Reservation
• DHCP Client List
• Server
MANAGEMENT
• Deco App
TEST DATA
• Wi-Fi Transmission Power (CE)
– ≤20dBm (2.4GHz)
– ≤23dBm (5GHz)
PHYSICAL
• Dimensions: 210.5 × 130 × 123mm
CERTIFICATION
• RoHS
• CE
• RCM
ENVIRONMENT
• Operating Temperature: 0~40°C
• Storage Temperature: -40~60°C
• Operating Humidity: 10~90%RH
• Storage Humidity: 5~90%RH
