FEATURES
• AX3000 Dual-Band Wi-Fi 6 – 2,402Mbps (5.0GHz) plus 574Mbps (2.4GHz)
• Multiple Installation Options – Place it on a tabletop or install it on a ceiling or wall with the adaptive accessories
• PoE Supported – Power over Ethernet for simplified network deployment
• Multi-Gig 2.5Gbps Wired Network – 1× 2.5Gbps port plus 1× Gigabit port
• Seamless AI-Driven Mesh – Intelligently learns your network environment to provide the ideal Wi-Fi unique to your home
• TP-Link HomeShield – Provides comprehensive network protection, robust parental controls and real-time IoT security
• Setup Made Easier Than Ever – The Deco App walks you through setup step-by-step
SPECIFICATIONS
SECURITY
NETWORK SECURITY
• SPI Firewall
• Access Control
• HomeShield Security
• Real-Time IoT Protection
• Malicious Site Blocker
• Intrusion Prevention System
• DDoS Attack Prevention
• Home Network Scanner
GUEST NETWORK
• 1× 5.0GHz Guest Network
• 1× 2.4GHz Guest Network
WI-FI ENCRYPTION
• WPA-Personal
• WPA2-Personal
• WPA3-Personal
WIRELESS
WIRELESS STANDARDS
• Wi-Fi 6
• IEEE 802.11ax/ac/n/a 5.0GHz
• IEEE 802.11ax/n/b/g 2.4GHz
WI-FI SPEEDS
• AX3000
• 5.0GHz: 2,402Mbps (802.11ax, HE160)
• 2.4GHz: 574Mbps (802.11ax)
WI-FI RANGE AND MESH
• TP-Link Mesh Technology
• AI-Driven Mesh
• Optional Ethernet Backhaul
• 4× Internal Antennas
• Signal-Boosting Antenna Array
WI-FI CAPACITY
• Dual-Band
• 2×2 MU-MIMO
• OFDMA
• 4 Streams
WORKING MODES
• Router Mode
• Access Point Mode
HARDWARE FEATURES
POWER SUPPLY
• IEEE 802.3at PoE
• 12V DC
• 12V 1A DC Adapter Included
HARDWARE
BUTTON
• Reset Button
ETHERNET PORTS
• 1× 2.5Gb Port plus 1× Gigabit Port per Deco Unit
• Supports WAN/LAN Auto-Sensing
SOFTWARE
PROTOCOLS
• IPv4
• IPv6
SERVICE KIT
• HomeShield
PARENTAL CONTROLS
• Custom Profiles
• Professional Content Filter Library
• Family Time
• Bedtime
• Off Time
• Time Rewards
• Family Online Time Ranking
• Pause The Internet
• Weekly and Monthly Reports
WAN TYPES
• Dynamic IP
• Static IP
• PPPoE
• L2TP
• PPTP
QUALITY OF SERVICE
• HomeShield QoS
• QoS by Device
CLOUD SERVICE
• OTA Firmware Upgrade
• TP-Link ID
• DDNS
NAT FORWARDING
• Port Forwarding
• UPnP
IPTV
• IGMP Proxy
• IGMP Snooping
• Bridge
• Tag VLAN
DHCP
• Address Reservation
• DHCP Client List
• Server
DDNS
• TP-Link
MANAGEMENT
• Deco App
TEST DATA
WI-FI TRANSMISSION POWER
• CE: ≤20dBm (2.4GHz), ≤23dBm (5.0GHz)
• FCC: ≤30dBm (2.4GHz), ≤30dBm (5.0GHz)
PHYSICAL
• Dimensions: 154 × 154 × 68mm
CERTIFICATIONS
• CE
• FCC
• RoHS
ENVIRONMENT
• Operating Temperature: 0~40°C
• Storage Temperature: -40~60°C
• Operating Humidity: 10~90%RH
• Storage Humidity: 5~90%RH
