FEATURES
• Weatherproof Outdoor Design – Durable enclosure built for reliable outdoor Wi-Fi deployment
• AC1200 Dual-Band Performance – Up to 1200Mbps with 2×2 MIMO technology for stable high-speed connectivity
• Extended Long-Range Coverage – High transmission power and high-gain antennas maximise outdoor signal reach
• Centralised Omada Management – Free Omada Controller Software supports large-scale multi-AP administration
• Built-In Captive Portal – Provides simple and secure guest authentication
• Facebook Wi-Fi and SMS Login – Enhances customer engagement and business marketing opportunities
• Flexible PoE Deployment – Supports 802.3af and Passive PoE with included adapter and easy mounting design
SPECIFICATIONS
HARDWARE FEATURES
INTERFACE
• 1× Gigabit Ethernet (RJ45) Port (Supports 802.3af PoE and Passive PoE)
BUTTON
• Reset
POWER SUPPLY
• 802.3af/at PoE
• 24V Passive PoE (+4,5pins; -7,8pins)
• PoE Adapter Included
POWER CONSUMPTION
• 10.5W
DIMENSIONS (W × D × H)
• 215 × 46 × 27mm
ANTENNA
• 2.4GHz: 2× 3dBi
• 5.0GHz: 2× 4dBi
WEATHERPROOF ENCLOSURE
• IP65
MOUNTING
• Pole / Wall Mounting Kits Included
HARDWARE WATCH DOG
• Yes
WIRELESS FEATURES
WIRELESS STANDARDS
• IEEE 802.11a/b/g/n/ac
FREQUENCY
• 2.4GHz and 5.0GHz
SIGNAL RATE
• 5.0GHz: up to 867Mbps
• 2.4GHz: up to 300Mbps
WIRELESS FUNCTIONS
• Multiple SSIDs (up to 16× SSIDs, 8× per Band)
• Enable/Disable Wireless Radio
• Automatic Channel Assignment
• Transmit Power Control
• QoS (WMM)
• MU-MIMO
• Airtime Fairness
• Beamforming
• Band Steering
• Load Balance
• Rate Limit
• Reboot Schedule
• Wireless Schedule
• Wireless Statistics (SSID/AP/Client Based)
WIRELESS SECURITY
• Captive Portal Authentication
• Access Control
• Wireless MAC Address Filtering
• Wireless Isolation Between Clients
• SSID to VLAN Mapping
• Rogue AP Detection
• 802.1X Support
TRANSMISSION POWER
CE
• <20dBm (2.4GHz, EIRP)
• <25dBm (5.0GHz, EIRP)
FCC
• <23dBm (2.4GHz)
• <22dBm (5.0GHz)
MANAGEMENT
• Omada App
• Omada Cloud Controller
• Omada Controller Software
• Cloud Access
• Email Alerts
• Management MAC Access Control
• System Logging (Local/Remote Syslog)
• SSH
• Web-Based Management
• L3 Management
• Multi-Site Management
• Management VLAN
CERTIFICATION
• CE
• FCC
• RoHS
