FEATURES
• 867Mbps 802.11ac Performance – Delivers up to 867Mbps on 5.0GHz for high-speed wireless backhaul and connectivity
• Long-Range Wireless Transmission – Ideal for outdoor links up to 1km
• Auto-Pairing With Agile LEDs – Enables fast deployment and clear signal alignment
• 3× Gigabit Ethernet Ports – Supports multiple high-speed IP camera connections
• Omada SDN Supported – Enables remote and centralised cloud management
• IP65 Weatherproof With 6kV Lightning Protection – Built for reliable all-weather outdoor operation
• Passive PoE Included – Flexible deployment with simplified power and data installation
SPECIFICATIONS
HARDWARE FEATURES
INTERFACE
• 3× Gigabit Ethernet Ports
BUTTON
• Reset
POWER SUPPLY
• 12V DC
• 24V Passive PoE (Adapter Included)
POWER CONSUMPTION
• 11.5W
DIMENSIONS (W × D × H)
• 79 × 60 × 224mm
ANTENNA
• Internal 2× Dual-Polarised Directional MIMO Antennas
• 5.0GHz: 7dBi
• Beamwidth: 70° Horizontal, 70° Vertical
WEATHERPROOF ENCLOSURE
• IP65
MOUNTING
• Pole Mounting (Accessories Included)
WIRELESS FEATURES
COVERAGE
• Up to 1000m
WIRELESS STANDARDS
• IEEE 802.11a/b/g/n/ac
FREQUENCY
• 5.0GHz
SIGNAL RATE
• up to 867Mbps
WIRELESS FUNCTIONS
• Mesh
• 5G 2×2 MU-MIMO (DL)
• Load Balance
• Seamless Roaming (802.11r)
• Beamforming
• Airtime Fairness
• Up to 8 SSIDs
• Wireless Statistics
• Wireless Schedule
• Reboot Schedule
• RADIUS Accounting
• MAC Authentication
• Static IP / Dynamic IP
WIRELESS SECURITY
• VLAN Support
• Access Control
• Rogue AP Detection
• Captive Portal Authentication
• Maximum MAC Filter Entries: 4,000
• WPA-Personal / Enterprise
• WPA2-Personal / Enterprise
TRANSMISSION POWER
CE
• <23dBm (5.0GHz Band 1/2, EIRP)
• <30dBm (5.0GHz Band 3, EIRP)
FCC
• <22dBm (5.0GHz Band 1/4)
MANAGEMENT
• Omada App
• Restore and Backup
• Firmware Update via Web
• NTP
CENTRALISED MANAGEMENT
• Omada Hardware Controller (OC300, OC200)
• Omada Software Controller
• Omada Cloud-Based Controller
CLOUD ACCESS
• Yes (Requires OC300, OC200, Omada Software Controller or Cloud-Based Controller)
• LED On/Off Control
• Management MAC Access Control
• SNMP v1/v2c/v3
• SSH
• Web-Based Management
CERTIFICATION
• CE
• FCC
• RoHS
ENVIRONMENT
• Operating Temperature: -40~70°C
• Storage Temperature: -40~70°C
• Operating Humidity: 10~90% Non-Condensing
• Storage Humidity: 5~90% Non-Condensing
