FEATURES
• 4K HDMI Video Output and 16MP Decoding Capacity – Sharp image definition up to 8MP and 8-Channel @2MP decoding capacity allows you to enjoy more channels live view and playback at the same time
• 90W PoE Budget – 16× 802.3af/at-compliant PoE+ ports with a total power supply of 90W
• 16-Channel Simultaneous Playback – Replay the feed from up to 16× cameras at the same time, increase replay speed and find events in the video schedule to easily review footage
• H.265+ – Compresses the video size without sacrificing video quality, easing the network load and saving disk space
• ONVIF Ensures Compatibility – Easily add IPCs from VIGI and other brands to establish a powerful and varied network thanks to barrier-free compatibility
• Auto Initialise for Quick Configuration – Just click “Auto Initialize” to set up basic IPC and hard disk parameters, significantly reducing your configuration time
• 24/7 Continuous Recording – Stores up to 20TB of footage (1,048 storage days) from connected cameras to secure your data for quick, convenient access
• Two-Way Audio – With voice intercom support, scare off any potential thieves or intruders from wherever you are
• Remote Monitoring – The dedicated VIGI App and client enable remote monitoring, providing ease and convenience
SPECIFICATIONS
VIDEO AND AUDIO
• IP Video Input: 16-Channel
• Incoming Bandwidth: 80Mbps
• Outgoing Bandwidth: 60Mbps
• HDMI Output Resolution: 1-Channel, Resolution: 3840 × 2160 @30Hz, 1920 × 1080 @60Hz, 1680 × 1050 @60Hz, 1440 × 900 @60Hz, 1280 × 1024 @60Hz, 1280 × 720 @60Hz
• VGA Output Resolution: 1-Channel, Resolution: 1920 × 1080 @60Hz, 1680 × 1050 @60Hz, 1440 × 900 @60Hz, 1280 × 1024 @60Hz, 1280 × 720 @60Hz
• Video Output Mode: HDMI/VGA Simultaneous Output
• Multi-View Display: 1/4/6/8/9/16
DECODING
• Audio Compression: G.711A/G.711U/G.726
• Video Compression: H.265+/H.265/ H.264+/H.264
• Record Resolution: 8MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
• Synchronous Playback: 16-Channel
• Capability: 25fps:
• 2-CH @8MP, 4-CH @4MP, 8-CH @2MP
• 30fps:
• 4-CH @3MP, 2-CH @5MP
RECORD MANAGEMENT
• Record Mode: Manual Recording, Scheduling Recording, Motion Detection Recording
• Playback Mode: Instant Playback, Regular Playback, Tag Playback, Event Playback
• Backup Mode: Regular Backup, Video Clip Backup
• Playback Function: Play, Pause, Stop, Fast Forward, Fast Backward, Play By Frame, Full
• Screen, Video Clip, Export Clip, Digital Zoom, Lock Recording, Audio On/Off
NETWORK
• Protocol: UPnP (Plug and Play), NTP (Network Timing)
• Mobile Phone Access: Android, iOS
• Web Browser: Chrome (57+), Firefox (52+), Edge (91+)
• Interoperability: ONVIF, CGI
EXTERNAL INTERFACE
• Network Interface: 1× RJ45 10/100/1000Mbps Self-Adaptive Ethernet Interface
• USB Interface: 1× Front USB2.0 Port, 1× Rear USB2.0 Port
• Audio Interface: 1× Audio In; 1× Audio Out
• Alarm In/Out: N/A
• Serial Interface: N/A
• Power: 1× DC Jack
• Reset Button: 1×
• Speaker: N/A
• eSATA: 1×
• HDMI: 1×
• VGA: 1×
HARD DISK
• SATA: 2× SATA Interfaces
• Capacity: Up to 10TB Capacity for Each HDD
• POE Standard: 802.3at/af Compliant
• Interface: 16× RJ45 10/100Mbps Self-Adaptive Ethernet Interface PoE Budget: 90W Available for All PoE+ Ports, 30W Max. per Port
ALARM
• General Alarm: Motion Detection, Video Tampering, Line-Crossing Detection, Intrusion Detection, Region Entering Detection, Region Exiting Detection, Object Abandoned/Removal Detection, Vehicle Detection, Human Detection, Smart Frame
• Anomaly Alarm: Video Loss, Offline and IP Conflict, Disk Exception, Login Exception, Fan Exception
• Alarm Linkage: Recording, White Light Alarm, Buzzer, Log, Audible Alarm
GENERAL
• Storage Temperature: -40~70°C
• Storage Humidity: 10%~90% RH Non-Condensing
• Working Temperature: NVR: -10~55°C
• Power Adapter: 0~40°C
• Working Humidity: 10%~90% RH Non-Condensing
• Dimensions (W × D × H): 330 × 285 × 45mm
• Net Weight: 1.9kg
• Gross Weight: 3.2kg
• Power Supply: 53.5V DC 2.43A
• Power Consumption: 6.2W (Without Disk)
• 40W (With Disk)
• Certifications: CE, EAC, UKCA, RCM, Triman, BSMI, VCCI, FCC, IC, HDMI
